Lenovo Type 4337 ThinkPad Mini Dock III Docking Station USB 3.0 Kit inc Adapter

The ThinkPad Mini Dock Series 3 is ideal for notebook users who need easy access to the Internet/LAN, multiple USB devices, audio and video equipment. It offers convenient eject button for one-step system removal in a hurry and with all Thinkpad docks, has been designed to keep your desk free from the clutter of messy wires. There are multiple video ports onboard, and the video controller allows for any two video ports to be used simultaneously giving it the edge over its -little brother-, the "Port Replicator Series III"

The Lenovo ThinkPad Mini Dock Series 3 (III) offers connections for notebook ports including power pass-through. It comes without integrated power supply but provides the same power jack as found in a ThinkPad, so you need to use either your ThinkPad AC adapter or another IBM AC adapter (Must be 90W or higher). Besides all the pass-through ports the Port Replicator Series 3 (III) comes with an On/Off switch and a slot for a Kensington cable lock which secures the device and prevents the ThinkPad dock from being removed. This Port Replicator / Docking station allows for permanent connection of peripheral devices at your desk with no need to keep plugging / unplugging cables each time you want to work.

Type: 4337 USB 3.0 P/N: 0B56232, 0A65688. 0C10040, SD20A23326, SD20A23329, 433715U (90W US), 433715J, 0A65691, 0A65692, 0A65693, 0A65694, 0A65695, 0A65696, 0A65697, 0A65698, 433715X, 433715P, 0A65684, 0A65685, 0A65686, 0A65687, 0A65689, 0A65690 USB 3.0 FRU: 04W3587, 04Y2072, 04W3940, 04Y2075, 0A65683 This docking station is the USB 3.0 version but it also shares the same compatibility with the following USB 2.0 part numbers. If your laptop does not feature USB 3.0 (Blue) then your laptop will run at standard USB 2.0 speeds on this dock. USB 2.0 P/N: 0B00031 45N5887, 75Y5732, 45N6678, 45N6679, 45N6680, 45N6681, 45N6682, 45N6683, 45N6684, 45N6685, 45N6686, 45N6688, 45N6689, 45N6690, 45N6691, 45N6692, 433710J, 433710P, 433710U, 433710X, 0A70349, 75Y5735, 04W1502, 45N6678, 4337IOU USB 2.0 FRU: 04W1816 45M2489 75Y5733 75Y5908, 04W0485, 75Y5734, 45M1270, 45M2489 Misc P/N: 4337-15G

Includes Genuine IBM 90W PSU AC Adapter with UK Mains Lead.

Ports: Ethernet (RJ45) VGA DVI-D (1920 x 1200) DisplayPort Audio-In Audio-Out USB 2.0 x5 USB 3.0 x1 Kensington Lock Connector Please note that this model does have a lock present includes two keys.

Compatible with the following laptop(s): Requires 20V 4.5A (90W) 7.9mm x 5.5mm: ThinkPad L412*, L420*, L430, L512*, L520*, L530, T400s*, T410*, T410i*, T410s*, T410si*, T420*, T420s, T430, T510*, T510i*, T520* (Dual Core), T520i* (Dual Core), T530 (Dual Core), T530i (Dual Core), X220*, X220i*, X230, X230i Requires 20V 4.5A (90W) 7.9mm x 5.5mm AND docking adapter (P/N: 04X0856, 04X0856): ThinkPad T430s, T431s *Does not support USB 3.0. The USB 3.0 port on this docking station will run at USB 2.0 speeds.
